Output |
3LED |
3LEDT |
6LED |
9LED |
ZDC |
Halogen Lumen Equivalent |
20W |
20W |
35W |
50W |
20W |
Total Lumens† |
225 |
121 |
445 |
600 |
140 |
Input Voltage |
10 to 15V |
10 to 15V |
10 to 15V |
10 to 15V |
11 to 15V |
Input Power (W) |
4.2 |
4.2 |
8.2 |
10 |
9.1 |
VA |
4.5 |
4.5 |
9.7 |
10.7 |
11 |
Efficacy (Lumens/Watt) |
54 |
34 |
54 |
46 |
26 |
Color Rendering Index (CRI) |
84 |
-- |
84 |
84 |
81 |
Center Beam Candlepower* |
|
|
|
|
|
Spot (17-20) |
1,100 |
492 |
2,700 |
3,500 |
170 |
Dimming |
PWM, Phase** |
PWM, Phase** |
PWM, Phase** |
PWM, Phase** |
-- |
RGBW Available |
No |
No |
No |
No |
Yes |
Luxor Compatibility |
|
|
|
|
|
Default |
Zoning |
-- |
Zoning |
Zoning |
-- |
ZD Option |
Zoning/Dimming |
Zoning/Dimming |
Zoning/Dimming |
Zoning/Dimming |
-- |
ZDC Option |
-- |
-- |
-- |
-- |
Zoning/Dimming/Color |
Minimum Rated Life (L70) |
50,000 Hrs |
50,000 Hrs |
50,000 Hrs |
50,000 Hrs |
50,000 Hrs |
* Information not available for Flood or Wide Flood.
** For optimal performance, use a trailing-edge, phase-cut dimmer.
† Measured using the 3,900K CCT lens. Multipliers for other CCTs include 0.80 (2,700K), 0.65 (4,500K), and 0.65 (5,200K).
