| Output |
1 LED |
3 LED |
ZDC |
| Total Lumens† |
49 |
132 |
166 |
| Input Voltage |
10 to 15 V |
10 to 15 V |
11 to 15 V |
| Input Power |
2.0 W |
4.2 W |
6.0 W |
| Power Consumption (VA) |
2.4 |
4.5 |
7.2 |
| Efficacy (lm/W) |
24 |
32 |
24 |
| Color Rendering Index (CRI) |
80+ |
80+ |
80+ |
| Max Candela |
38 |
80 |
108 |
| Dimming |
|
|
|
Primary Dimming
(Transformer) |
Consult transformer specifications |
Secondary Dimming
(Fixture) |
Phase-cut** |
Phase-cut** |
Luxor |
| RGBW Available |
No |
No |
Yes |
| Luxor Compatibility |
|
|
|
| Default |
Zoning |
Zoning |
-- |
| ZD Option |
Zoning/Dimming |
Zoning/Dimming |
-- |
| ZDC Option |
-- |
-- |
Zoning/Dimming/Color |
| Minimum Rated Life L90 B10 |
55,000 Hrs |
55,000 Hrs |
55,000 Hrs |
† Measured using the 3,900K CCT lens. Multipliers for other CCTs include 0.80 (2,700K), 0.65 (4,500K), and 0.65 (5,200K).
** For optimal performance, use a trailing-edge, (reverse phase-cut) dimmer.
